back

Product Options

A+B
LR
AF
AAF
LS

Application: GC03-AB

Product Type: A & B

Product Material: Malleable Iron (Zinc Plated or Hot Dip Galvanised)

Beam to beam (equal widths) crossing at 0°

Supporting Section: Beam
Supported Section: Beam (equal width)
Connection Components: Location plate, 8 clamps and 4 bolts, nuts & washers

Create a PDF Enquire about connection

Safe Working Loads

Clamp Size	Tension Capacity	Slip Capacity
M12	23.2 kN	1.8 kN
M16	34 kN	3.4 kN
M20	58.8 kN	6 kN
M24	78.8 kN	9 kN

View Products

Type A Girder Clamp

Standard girder clamp used to quickly connect steel beams…

Type B Girder Clamp

Standard girder clamp, with flat top, used to quickly…

Application: GC03-LR

Product Type: LR

Product Material: Malleable Iron (Zinc Plated or Hot Dip Galvanised)

Beam to beam (equal widths) crossing at 0°

Supporting Section: Beam
Supported Section: Beam (equal width)
Connection Components: Location plate, 8 clamps and 4 bolts, nuts & washers

Create a PDF Enquire about connection

Safe Working Loads

Clamp Size	Tension Capacity	Slip Capacity
M12	23.2 kN	1.8 kN
M16	34 kN	3.4 kN
M20	58.8 kN	6 kN
M24	78.8 kN	9 kN

View Products

Type LR Girder Clamp

Self-adjusting girder clamp used to quickly connect steel…

Application: GC03-AF

Product Type: AF

Product Material: SG Iron (Hot Dip Galvanised)

Beam to beam (equal widths) crossing at 0°

Supporting Section: Beam
Supported Section: Beam (equal width)
Connection Components: Location plate, 8 clamps and 4 bolts, nuts & washers

Create a PDF Enquire about connection

Safe Working Loads

Clamp Size	Tension Capacity (8.8 Bolts)	Tension Capacity (10.9 Bolts)	Slip Capacity (8.8 Bolts)	Slip Capacity (10.9 Bolts)
M12	34 kN	40 kN	6.8 kN	8 kN
M16	64 kN	78 kN	16 kN	22 kN
M20	105.2 kN	120 kN	26 kN	40 kN
M24	160 kN	250 kN	48 kN	56 kN

View Products

Type AF High Slip Resistance Girder Clamp

Heavy duty girder clamp used to quickly connect steel beams…

Application: GC03-AAF

Product Type: AAF

Product Material: Low Temperature SG Iron (Hot Dip Galvanised)

Beam to beam (equal widths) crossing at 0°

Supporting Section: Beam
Supported Section: Beam (equal width)
Connection Components: Location plate, 8 clamps and 4 bolts, nuts & washers

Create a PDF Enquire about connection

Safe Working Loads

Clamp Size	Tension Capacity (8.8 Bolts)	Tension Capacity (10.9 Bolts)	Slip Capacity (8.8 Bolts)	Slip Capacity (10.9 Bolts)
M12	34 kN	40 kN	6.8 kN	8 kN
M16	64 kN	78 kN	16 kN	22 kN
M20	105.2 kN	120 kN	26 kN	40 kN

View Products

Type AAF High Slip Resistance Girder Clamp

Adjustable girder clamp used to quickly connect steel beams…

Application: GC03-LS

Product Type: LS

Product Material: Cast Stainless Steel Grade 316

Beam to beam (equal widths) crossing at 0°

Supporting Section: Beam
Supported Section: Beam (equal width)
Connection Components: Location plate, 8 clamps and 4 bolts, nuts & washers

Create a PDF Enquire about connection

Safe Working Loads

Clamp Size	Tension Capacity	Slip Capacity
M10	12 kN	3 kN
M12	28 kN	4 kN
M16	40 kN	6 kN
M20	72 kN	10 kN

View Products

Type LS Girder Clamp

Stainless steel, self-adjusting girder clamp used to…
